| Input |
(2) line inputs. (1) RTA Mic input |
| Input Connectors |
(2) Female XLR line inputs. XLR RTA Mic input |
| Input Type |
Electronically balanced/RF filtered |
| Input Impedance |
>40k ohm |
| Max Input |
+30dBu with input jumpers in +30 position |
| CMRR |
> 45dB |
| Mic Preamp Phantom Power |
+15VDC (RTA) |
| Mic Preamp Equivalent Input Noise (EIN) |
< -110dB, 22Hz-22kHz, 150 ohm (RTA) |
| Output |
6 total |
| Output Connectors |
Male XLR |
| Output Type |
Electronically balanced, RF filtered |
| Output Impedance |
120ohm |
| Max Output |
+22dBu |
| A/D Converter |
dbx Type IV™ Conversion System |
| A/D Dynamic Range |
(line) >113 dB, A-weighted, >110 dB unweighted |
| Type IV Dynamic Range |
>119 dB, A-weighted, 22kHz BW; >117 dB, A-weighted, 22kHz BW |
| Sample Rate |
48kHz |
| D/A Dynamic Range |
112 dB A-weighted, 109dB unweighted |
| Dynamic Range |
>110 dB A-weighted, >107dB unweighted |
| THD+Noise |
0.003% typical at +4dBu, 1kHz, 0dB gain |
| Frequency Response |
20Hz – 20kHz, +/- 0.5dB |
| Interchannel Crosstalk |
>110dB, 120dB typical, (input-to-output: >100dB) |
